Novametrix Medical Systems MARS PO2 TECH 2001 Service Manual page 60

Section 12
Parts Lists
Seq
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
54
Model 2001 Service Manual
Itern Nbr Description
481501 DIODE, 1N4148, SIGNAL
472274 RESISTOR, 26.7 OHM, 1/4W
472105 RESISTOR, 3.92K OHM, 1/4W
470109 RESISTOR, 470K OHM, 1/2W
481534 DIODE, BAT82, SCHOTTKY
2471-28 MAIN BD KIT, 520A, 2001
472227 RESISTOR, 47 OHM, 1/4W
474134 RESISTOR PACK, 41K OHM
5712-10 TRANSFORMER, MAIN BD
486299 IC, CS5503JP, 20-BIT A TO D
472170 RESISTOR, 22.1K OHM, 1/4W
474132 RESISTOR PACK, 41K OHM
472276 RESISTOR, 6.49K OHM, 1/4W
470016 RESISTOR, 22 OHM, 1/4W
472268 RESISTOR, 8.66K OHM, 1/4W
5833-01 GROUND WIRE ASSY
472003 RESISTOR, 100 OHM, 1/4W
472146 RESISTOR, 47.5K OHM, 1/4W
152072 CAPACITOR, TOUF, 50V
472246 RESISTOR, 66.5K OHM, 1/4W
472198 RESISTOR, 3.3 OHM, 1/4W
474098 RESISTOR PACK, 100K
153027 CAPACITOR, 220PF, 50V
472030 RESISTOR, 10K OHM, 1/4W
474133 RESISTOR PACK, 10 OHM, 2%
474086 RESISTOR PACK, 10K OHM
5711-10 TRANSFORMER, MAIN BD
472034 RESISTOR, 12.1K OHM, 1/4W
153063 CAPACITOR, 220PF, 3KV
152075 CAPACITOR, 47UF, 25V, 20%
474138 RESISTOR, 100 OHM, 1/8W
154016 CAPACITOR, .1UF, 50V, 10%
216029 TEST POINT, SPRING LOADED
152045 CAPACITOR, lOUF 16V
153052 CAPACITOR, .022UF, 50V
152073 CAPACITOR, 100UF, 16V
153021 CAPACITOR, .47UF,MULTILAY
472195 RESISTOR, 41.2K OHM, 1/4W
180011 FERRITE BEAD, 22 AWG
153051 CAPACITOR, .22UF, 50V, 20%
474135 RES PACK, 100 OHM, 2%
481031 DIODE, ZENER, BZX79-C7V5
472037 RESISTOR, 13.7K OHM, 1/4W
180067 FERRITE BEAD, 600 OHM
215080 SOCKET, 32 PIN, PLCC
481050 ESD SUPPRESSOR, 1206 SIZE
212136 CONN, 10 PIN, HDR, BD STK
Qty
9
1
2
1
2
1
2
1
1
2
1
2
2
1
1
1.
2
1
1
2
1
4
1
7
1
1
0
1
2
2
4
59
2
6
1
4
1
4
1
1
1
1
2
15
1
2
1
Rev. 01
