Parts Lists - Novametrix Medical Systems MARS PO2 TECH 2001 Service Manual

Section 12
9400-00 PULSE OXIMETER, 2001
Seq
002
003
004
009
010
011
012
013
014
015
016
017
019
025
026
9400-01MAIN ASSEMBLY, 2001
Seq
001
002
003
004
005
006
007
008
009
014
015
016
017
018
Rev. 01
Item Nbr Description
286205 6-32 X 3/4 S.B.H. CAD PLA
315032 LABEL, 120VAC
600026 LINE CORD, AC, 7 1/2 FT,
1003-32 LABEL, SERIAL NUMBER
1217-32 REPAIR LABEL
4470-32 LABEL, CAUTION GROUNDING
6642-32 INSTRUCTION SHEET, BATTERY
6965-32 REGULATORY LABEL, UL MARK
6986-32 BATTERY LABEL
7104-10 SIDE POUCH, ACCESSORY
9026-32 LABEL, MANUFACTURED IN USA
9400-01 MAIN ASSEMBLY, 2001
9400-09 OVERALL WIRING DIAG, 2001
9621-16 LENS, ALERT, MODEL 515
9629-01 TOP CVR ASSY, 2001
Item Nbr Description
2775A-01 MAIN BOARD ASSY, 2001
5664-10 CHASSIS, MODEL 520A
5713-01 SPEAKER ASSY
5714-01 BATTERY HARNESS ASSY
5728-01 CABLE ASSY, SPO2 INPUT
6815-10 INSULATING SHIELD
9386-01 REAR PANEL ASSY, 2001
9625-01 FRONT PANEL ASSY, 2001
9630-01 BOTTOM COVER ASSY, 2001
140002 CARD GUIDE
161067 TAPE
284200 #4-40 X 1/4 SLOTTED
286220 SCREW, 6-32 X 3/16, SLTD
400024 BATTERY, l2VDC, 2.3AH

Parts Lists

Qty
0
1
1
1
1
1
1
1
1
1
1
1
0
1
1
Qty
1
1
1
1
1
1
1
1
1
2
0
0
0
1
Model 2001 Service Manual
51
