Novametrix Medical Systems MARS PO2 TECH 2001 Service Manual page 63

Seq
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
004
004
2726-01 POWER SUPPLY BD ASSY
Seq
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
Rev. 01
Item Nbr Description
154057 CAPACITOR, 470pF
485527 MOSFET, 1RF9523
211412 CONNECTOR, 4 PIN
484014 NPN TRANSISTOR
486276 IC, LT1O81CN
180004 CHOKE, 100UH, 10%,
215031 SOCKET, 20 PIN, DIP,
211213 CONNECTOR, 2 PIN
211629 CONNECTOR, 6 PIN
470111 RESISTOR, .33 OHM
153046 CAPACITOR, 4700PF
486606 CD4O93SE
152066 CAPACITOR, 220uF
485520 TRANSISTOR, 55250
212529 CONNECTOR, 20 PIN
484515 LM317LZ REGULATOR
215055 SOCKET, IC
515072 FUSE, 1A, 125V,
487065 IC, UC3843N
400035 INVERTER,
210051 CONNECTOR, 25 PIN,
180011 FERRITE BEAD, 22 AWG
487053 IC, AD712JN
486717 LF353N DUAL BI-FET AMP
Item Nbr Description
211505 CONNECTOR, 5 PIN, SQ
474145 RESISTOR, 215 OHM, 1
481530 DIODE, KBU4G, 4 AMP,
474214 RESISTOR, 332K OHM,
474137 RESISTOR, 1M OHM, 1/
481549 DIODE, MBRS14OT3, RE
152096 CAPACITOR, 220UF, 35
484529 VOLTAGE REGULATOR, L
180014 INDUCTOR, 25UH, .25
474165 RESISTOR, 10K OHM, 1
152081 CAPACITOR, G800UF, 3
474162 RESISTOR, 61.9K OHM,
5918-10 XFMR, MAINS, PWR SPL
470026 RESISTOR, 150 OHM, 1
474215 RESISTOR, 2.21K OHM,
486805 IC, LM393M, DUAL VOL
2725-02 FAB, POWER SUPPLY BO
515085 FUSE W FUSEHOLDER, 2
474141 RESISTOR, 249K OHM,
2726-04 TEST PROCEDURE, PWR
Section 12
Parts Lists
Qty
1
1
1
1
1
1
2
2
1
3
1
1
1
2
1
1
1
1
1
1
1
1
2
2
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
Model 2001 Service Manual
57
