Section 12
Parts Lists
9629-01TOP COVER ASSY, 2001
Seq
001
002
003
004
005
010
011
9630-01BOTTOM COVER ASSY, 2001
Seq
001
002
003
004
005
006
007
008
013
014
015
016
017
018
9625-01FRONT PANEL ASSY, 2001
Seq
001
002
003
004
006
007
008
009
010
9386-01REAR PANEL ASSY, 2001
Seq
001
002
003
004
005
52
Model 2001 Service Manual
Item Nbr Description
5828-32 ISOLATION LABEL, 520A, 12
5862-10 SHIELD, MYLAR, TOP COVER,
6427-32 WARNING LABEL, EXPLOSION
6867-13 TOP COVER
9629-32 INSTRUCTION LABEL
160044 ALCOHOL, ISOPROPYL, TECHN
161100 TAPE, FOAM, 3/4W X .312T,
Item Nbr Description
4727-10 KICKSTAND, BEDRAIL
5405-10 SHIELD, BATTERY
5409-32 LABEL, WARNING, POLE MOUNT
5760-16 LEFT FOOT, WHITE
5761-16 RIGHT FOOT, WHITE
5826-10 FOOT PAD, BOTTOM COVER
5849-10 BRACKET, SUPPORT
6868-13 BOTTOM COVER
160044 ALCOHOL, ISOPROPYL
161007 ADHESIVE, 414, HIGH STRENGTH
161064 TAPE, 3/4 X 60 YDS, CLEAR
284261 SCREW, 4-40 x 5/8 L, PHILIPS
284264 SCREW, 4-40 x 1/4 L, SLOTTED
315052 LABEL, EARTHING SYMBOL
Item Nbr Description
2473-01 ALERT BOARD ASSY
9625-27 MEMBRANE KEYPANEL, 2001
5720-01 DISPLAY ASSY
6278-10 SHIELD, VFD
280033 SPACER #4 X 1/2
280187 STANDOFF, .187 DIA x 5/8
284200 #4-40 x 1/4 SLOTTED
284204 #4-40 x 1/2 SLOTTED
285000 LOCK WASHER, NO. 4, INTER
Item Nbr Description
2726-01 PWR SPLY BD ASSY
4109-10 SUPPORT BRACKET, PC
5812-10 SPACER, SUPPORT,
5820-01 GROUND WIRE ASSY
6497-01 GROUND WIRE ASSY
Qty
1
1
1
1
1
0
0
Qty
1
1
1
2
2
4
1
1
0
0
0
0
0
1
Qty
1
1
1
1
0
0
0
0
0
Qty
1
1
2
1
1
Rev. 01
