Section 2
Introduction
Model 2001 is calibrated to display "functional" saturation. This differs from the "fractional"
saturation value displayed by most co-oximeters.
Equation 1. Functional
Saturation Calculation
Functional saturation represents the amount of oxyhemoglobin as a percentage of the
hemoglobin that can be oxygenated. Dysfunctional hemoglobins (COHb and METHb) are not
included in the measurement of functional saturation.
Pulse Rate is calculated by measuring the time interval between the peaks of the infrared light
waveform. The inverse of this measurement is displayed as pulse rate.
Model 2001 must be used in conjunction with SuperBright™ saturation sensors. (An CHECK
SENSOR SITE display message indicates a non-SuperBright™ Sensor may be in use.)

Indications and Usage

The Model 2001 Pulse Oximeter Monitor is intended to be used for monitoring oxygen
saturation and pulse rate in all critical monitoring environments including ventilatory support
and anesthesia. Model 2001 is designed to monitor all patient areas including adult, pediatric
and neonatal.

Symbols

Symbol
6
Model 2001 Service Manual
Functional Saturation =
HbO
COHb = Carboxyhemoglobin
METHb = Methemoglobin
Description
Patient Isolation
Identifies patient isolation connection as type BF.
Attention
Consult manual for detailed information.
!
Separate collection
Ensure that spent batteries are collected separately when
disposed of. Found on the internal battery. Refer to quali-
fied service personnel when battery replacement is
required.
Recyclable item
Found on the internal battery. Refer to qualified service
personnel when battery replacement is required.
Indicates heavy metal content, specifically lead. Found
Pb
on the internal battery and monitor enclosure. Refer to
qualified service personnel when battery replacement is
required.
100 - (COHb + METHb)
= Fractional Hemoglobin
2
Indications and Usage
HbO
2
