Novametrix Medical Systems MARS PO2 TECH 2001 Service Manual page 59

Seq
006
007
008
013
014
015
016
017
018
019
020
021
022
023
024
025
026
2775-01MAIN BOARD ASSY
Seq
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
Rev. 01
Item Nbr Description
6549-01 GROUND WIRE ASSY
9386-17 REAR PANEL SUBASSY
9387-01 PWR CABLE ASSY
161008 ADHESIVE
161092 ADHESIVE
210149 POWER ENTRY MODULE
216059 CONNECTOR, PLUG
280188 STANDOFF, 3/8 DIA
281500 NUT, HEX, NO. 4-40
281501 NUT, HEX, NO. 6-32
285000 LOCK WASHER, NO. 4
285001 LOCK WASHER, NO. 6
285005 FLAT WASHER, NO. 8
285013 NYL WASH, #4 NATURAL
286219 SCREW, 6-32 X 1 1/4
515023 FUSE, 1/2A, 250V
608033 WIRE CLIP & BUSHING
Itern Nbr Description
472121 RESISTOR, 3.74K OHM, 1/4W
483017 TRANSISTOR, BC2l4C, PNP
474032 RESISTOR, 10 OHM, 1/2W
472041 RESISTOR, 20K OHM, 1/4W
472063 RESISTOR, 162K OHM, 1/4W
472200 RESISTOR, 5.6 OHM, 1/4W
487064 IC, CNYl7-III, PHOTON COUPLED
154058 CAPACITOR, .022UF, 100V
472011 RESISTOR, 1K OHM, 1/4W
474089 RESISTOR PACK, 100K OHM
474131 RESISTOR PACK, 10K OHM
211306 CONNECTOR, 3 PIN, HEADER
180033 EMI FILTER, 22PF, 20%
472255 RESISTOR, 1 OHM, 1/4W, 1%
154065 CAP, .lUF, 63V, .2 (5MM)
152040 CAPACITOR, 2.2UF, 35V
472007 RESISTOR, 475 OHM, 1/4W
154081 CAPACITOR, 100PF, 100V
472021 RESISTOR, 4.75K OHM, 1/4W
210144 JUMPER, 2 POSITION, RECEPTACLE
153003 CAPACITOR, .0lUF,50V
472193 RESISTOR, 23.7K OHM, 1/4W
481541 DIODE, 100V, lA, FAST RECOVERY
475034 POTENTIOMETER, 2K OHM
483002 2N3906 PNP SILICON SWITCH
472058 RESISTOR, 100K OHM, 1/4W
154060 CAPACITOR, .22UF, 63V
Section 12
Parts Lists
Qty
1
1
1
0
0
1
1
0
0
0
0
0
0
0
0
2
1
Qty
1
4
1
2
1
1
4
1
5
2
1
1
1
2
5
3
6
5
1
1
1
1
4
1
1
7
1
Model 2001 Service Manual
53
