Sav182D and Sav36D:
Connect unswitched AC power 115VAC, 60Hz or 230VAC, 50Hz to black and white flying leads, which are
factory installed. Connect main incoming ground to the provided green grounding conductor lead.
To install 3-wire line cord with integral strain relief (supplied) refer to pages 9 and 10.
3. Unit is factory set at 12VDC. To adjust output voltage use the trimpot (Fig. 2a, pg. 4; Fig. 3a, pg. 5; Fig. 4a,
pg. 6; Fig. 5a pg. 7, Fig. 6a, pg. 8) on the power supply board(s), connect digital volt meter to the terminals
marked [OUT1 to OUT18] and slowly turn trimpot clockwise to increase voltage or counter-clockwise to
decrease voltage.
Note: Voltage will be the same for all outputs.
4. Measure output voltage before connecting devices. This helps avoiding potential damage.
5. Connect cameras to be powered to the terminals marked [OUT1] through [OUT4] (Sav4D) (Fig. 2, pg. 4),
[OUT1] through [OUT9] (Sav9D) (Fig. 3, pg. 5), [OUT1] through [OUT18] (Sav18D) (Fig. 4, pg. 6),
[OUT1] through [OUT9] on each power supply board (Sav182D) (Fig. 5, pg. 7), [OUT1] through [OUT18]
on each power supply board (Sav36D) (Fig. 6, pg. 8), carefully observing correct polarity.
6. Upon completion of wiring, secure enclosure door with screws (supplied).
Caution: Equipment to be installed/serviced by authorized/trained personnel only and should conform
to the National Electrical Code and all local codes.
Shut branch circuit power before installing/servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
Use 75˚C or higher rated UL insulated wiring for connecting the unit to the mains.
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level.
Model Terminal Legend
All
L, G, N
Sav4D OUT1 (– , +) through OUT4 (–, +)
Sav9D OUT1 (–, +) through OUT9 (–, +)
Sav18D
OUT1 (–, +) through OUT18 (–, +)
Sav182D
OUT1 (–, +) through OUT9 (–, +) (on both power supply boards)
Sav36D
OUT1 (–, +) through OUT18 (–, +) (on both power supply boards)
Model LED
All
AC
Sav4D
OUT1 through OUT4
Sav9D
OUT1 through OUT9
Sav18D OUT1 through OUT18
OUT1 through OUT9
Sav182D
(on both power supply boards)
OUT1 through OUT18
Sav36D
(on both power supply boards)
Sav4/9/18/182/36D Installation Guide

Maintenance:

Terminal Identification:

LED Identification:

ON
Normal operating condition.
Normal operating
condition.
Description
115VAC, 60Hz or
230VAC, 50Hz Input
12VDC power output.
OFF
Loss of AC, No DC output
No Power Output.
- 3 -
