Enclosure Dimensions for Sav4D, Sav9D, and Sav18D:
1.25"
(31.75mm)
Sav4/9/18/182/36D Installation Guide
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm)
0.6" (15.2mm)
1.125"
(28.6mm)
1"
(25.4mm)
0.6" (15.2mm)
1"
(25.4mm)
7.25" (184.2mm)
3.625" (92mm)
6.05" (153.7mm)
6.05" (153.7mm)
5.25" (133.35mm)
1.25"
(31.8mm)
0.6" (15.2mm)
1.125"
(28.6mm)
1"
(25.4mm)
0.6" (15.2mm)
1"
(25.4mm)
1"
(25.4mm)
1.25"
(31.75mm)
- 11 -
