SMP10C24X220 Series
Power Supply/Chargers

Installation Guide

Models Include:
SMP10C24X220
- 24VDC @ 10A total supply current.
SMP10PM24P4220
- 24VDC @ 10A total supply current
with supervision.
- Four (4) fuse protected outputs.
SMP10PM24P8220
- 24VDC @ 10A total supply current
with supervision.
- Eight (8) fuse protected outputs.
SMP10PM24P16220
- 24VDC @ 10A total supply current
with supervision.
- Sixteen (16) fuse protected outputs.
Rev. 012610
SMP10PMC24X220
- 24VDC @ 10A total supply current
with supervision.
SMP10PM24P4C220
- 24VDC @ 10A total supply current
with supervision.
- Four (4) PTC protected outputs.
SMP10PM24P8C220
- 24VDC @ 10A total supply current
with supervision.
- Eight (8) PTC protected outputs.
SMP10PM24P16C220
- 24VDC @ 10A total supply current
with supervision.
- Sixteen (16) PTC protected outputs.
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMP10C24X220 and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix SMP10C24X220

Summary of Contents for Altronix SMP10C24X220

  • Page 1: Installation Guide

    SMP10C24X220 Series Power Supply/Chargers Installation Guide Models Include: SMP10C24X220 SMP10PMC24X220 - 24VDC @ 10A total supply current. - 24VDC @ 10A total supply current with supervision. SMP10PM24P4220 SMP10PM24P4C220 - 24VDC @ 10A total supply current - 24VDC @ 10A total supply current with supervision.

  • Page 2: Specifications

    Overview: SMP10C24X220 Series units convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into a regulated 24VDC @ 10A continuous supply current (see specifications). SMP1024X220 Series Power Supply Configuration Reference Chart: 220VAC 24VDC Accessory Individual 50/60Hz Total Power Number...

  • Page 3: Led Diagnostics

    PD4/PD4CB/PD8/PD8CB/PD16W/PD16WCB - Power Distribution Module Terminal Legend Function/Description PD4/PD4CB PD8/PD8CB PD16W/PD16WCB 1P to 4P 1P to 8P 1P to 16P Positive DC power outputs. 1N to 4N 1N to 8N 1N to 16N Negative DC power outputs. SMP10C24X220 Series - 3 -...
  • Page 4 P O W E R O U T P U T S DC Output to devices From Power Supply DC Output to devices From Power Supply Board Board (Factory Installed) (Factory Installed) Optional Rechargeable Optional R - 4 - SMP10C24X220 Series Stand-by Battery Stand-b...
  • Page 5 From Power Supply Board (Factory Installed) Used on PTC Models For continuous protection against risk of fire replace fuses with same type and rating. 3.5A 250V PD16W/PD16WCB Optional Rechargeable Optional R SMP10C24X220 Series - 5 - Stand-by Battery Stand-b...

  • Page 6: Enclosure Dimensions

    (279mm) 0.9375” 1.40” (24mm) 1.40” (36mm) (36mm) 5.10” 5.10” (130mm) (130mm) 13.0” (330mm) 5.10” (130mm) 6.5625” (167mm) 0.9375” (24mm) 3.25” 3.25” (83mm) (83mm) 3.25” (83mm) 1.0” 1.0” (25mm) (25mm) 1.0” 10.5” 1.0” (25mm) (267mm) (25mm) - 6 - SMP10C24X220 Series...
  • Page 7 Notes: SMP10C24X220 Series - 7 -...
  • Page 8 Notes: Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime warranty, Made in U.S.A. IISMP10C24X220 - Rev. 012610...
