SMP10C12X220 Series
Power Supply/Chargers
Models Include:
SMP10C12X220
SMP10C12XX220
SMP10PMC12X220
SMP10PMC12XX220
- Single Output.
SMP10PM12P4220
- Four (4) Fuse Protected Outputs.
SMP10PM12P8220
- Eight (8) Fuse Protected Outputs.
SMP10PM12P16220
- Sixteen (16) Fuse Protected Outputs.
Installation Guide
Rev. 060712
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
SMP10PM12P4CB220
- Four (4) PTC Protected Outputs.
SMP10PM12P8CB220
Eight (8) PTC Protected Outputs.
SMP10PM12P16CB220
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix SMP10C12X220 Series
Summary of Contents for Altronix SMP10C12X220 Series
- Page 1 SMP10C12X220 Series Power Supply/Chargers Models Include: SMP10C12X220 SMP10C12XX220 SMP10PMC12X220 SMP10PMC12XX220 - Single Output. SMP10PM12P4220 SMP10PM12P4CB220 - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. SMP10PM12P8220 SMP10PM12P8CB220 - Eight (8) Fuse Protected Outputs. Eight (8) PTC Protected Outputs.
-
Page 2: Specifications
Overview: Altronix SMP10C12X220 Series power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into a regulated 12VDC output with up to 10A of continuous load current (see specifications). SMP10C12X220 Series Power Supply Configuration Reference Chart: 220VAC 12VDC... - Page 3 DC power is present. Contact rating 1A @ 120VAC / 28VDC. NC, C, NO Low battery threshold: 12VDC output threshold set @ approximately 10.5VDC. – BAT + Stand-by battery connections. Maximum charge rate 0.7A. *Note: Supervised models only SMP10C12X220 Series Installation Guide - 3 -...
- Page 4 Power Supply Power Board Distribution 220VAC Module(s) power AC FAIL mains Fig. 1b LOW BAT LED Diagnostics, pg. 3 C NO NC C --- BAT + --- DC + Optional Rechargeable Stand-by Battery - 4 - SMP10C12X220 Series Installation Guide...
-
Page 5: Power Supply Board
Fig. 2 Ground Power Supply Board 5A 250V C NO NC C --- BAT + --- DC + 220VAC power mains Optional Rechargeable 12VDC Stand-by Battery SMP10C12X220 Series Installation Guide - 5 -... - Page 6 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 outputs protected outputs Used on PTC Models For continuous protection against risk of fire replace fuses with same type and rating. 3.5A 250V - 6 - SMP10C12X220 Series Installation Guide...
- Page 7 SMP10PM12P8220, SMP10PM12P8CB220, SMP10PM12P16220, SMP10PM12P16CB220 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) Enclosure accommodates up to two (2) 12VDC/7AH batteries. Also available to accommodate up to two (2) 12VDC/12AH batteries (please contact Altronix). 1.40” 4.85” (123.2mm) 4.85” (123.2mm) 1.40”...
- Page 8 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IISMP10C12X220 Series...
