SMP10C12X Series
Power Supply/Charger
Installation Guide
Models Include:
SMP10C12X
SMP10C12XX
SMP10PMC12X
SMP10PMC12XX
- Single Output.
SMP10PM12P4
- Four (4) Fuse Protected Outputs.
SMP10PM12P8
- Eight (8) Fuse Protected Outputs.
SMP10PM12P16
- Sixteen (16) Fuse Protected Outputs.
Rev. 051105
SMP10PM12P4CB
- Four (4) PTC Protected Outputs.
SMP10PM12P8CB
- Eight (8) PTC Protected Outputs.
SMP10PM12P16CB
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix SMP10C12X Series
Summary of Contents for Altronix SMP10C12X Series
- Page 1 SMP10C12X Series Power Supply/Charger Installation Guide Models Include: SMP10C12X SMP10C12XX SMP10PMC12X SMP10PMC12XX - Single Output. SMP10PM12P4 SMP10PM12P4CB - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. SMP10PM12P8 SMP10PM12P8CB - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs.
-
Page 2: Specifications
Overview: Altronix SMP10C12X Series power supply/chargers convert a 115VAC, 60Hz input into a regulated 12VDC output with up to 10A of continuous load current (see specifications). SMP10C12X Series Power Supply Configuration Reference Chart: 115VAC 12VDC Accessory 50/60Hz Total Power Number... -
Page 3: Led Diagnostics
PD4/PD4CB/PD8/PD8CB/PD16W/PD16WCB - Power Distribution Module: Terminal Legend Function/Description PD4/PD4CB PD8/PD8CB PD16W/PD16WCB 1P to 4P 1P to 8P 1P to16P Positive DC power outputs. 1N to 4N 1N to 8N 1N to 16N Negative DC power outputs. SMP10C12X Series - 3 -... - Page 4 Lead Power Supply Power Board Distribution 115VAC Module(s) power mains AC FAIL Fig. 1b LOW BAT LED Diagnostics, pg. 3 C NO NC C --- BAT + --- DC + Optional Rechargeable 12VDC Stand-by Battery - 4 - SMP10C12X Series...
-
Page 5: Power Supply Board
Fig. 2 Power Supply Board 5A 250V C NO NC C --- BAT + --- DC + 115VAC power mains Green Lead Optional Rechargeable 12VDC Stand-by Battery SMP10C12X Series - 5 -... -
Page 6: Power Distribution Module(S)
9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 outputs protected outputs Used on PTC Models For continuous protection against risk of fire replace fuses with same type and rating. 3.5A 250V - 6 - SMP10C12X Series... - Page 7 SMP10C12X, SMP10PMC12X, SMP10PM12P4, SMP10PM12P4CB, SMP10PM12P8, SMP10PM12P8CB, SMP10PM12P16, SMP10PM12P16CB 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) Enclosure accommodates up to two (2) 12VDC/7AH batteries. Also available to accommodate up to two (2) 12VDC/12AH batteries (please contact Altronix). 1.40” 4.85” 4.85”...
- Page 8 (117.22mm) (38.1mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IISMP10C12X Series C27R...
