Specifications; Installation Instructions - Altronix SAV Series Installation Manual

Altronix Sav Power Supplies provide 12VDC distributed via four (4), nine (9), eighteen (18), thirty-six (36) Class 2 Rated
PTC protected power-limited auto-resettable outputs for powering surveillance cameras and other 12VDC devices.
Sav4D
5A
Sav9D
5A
Sav18D
5A
Sav182D
11A
Sav36D
11A
*Not to exceed total output current.
230VAC/50Hz operation is intended for use outside of the North American Markets only.
Input:
• 115VAC, 60Hz or 230VAC, 50Hz.
Output:
• 12VDC outputs (1.2A per device, 2.5A max.).
• Four (4), nine (9), eighteen (18) or thirty-six (36)
Class 2 Rated PTC protected power-limited outputs.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Features:
• Power LEDs.
• Unit maintains camera synchronization.
This installation should be made by qualified service personnel and should conform to all local codes and in
accordance with the National Electrical Code. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up
with the top two keyholes in the enclosure. Install two upper fasteners and screws
in the wall with the screw heads protruding. Place the enclosure's upper keyholes
over the two upper screws; level and secure. Mark the position of the lower two
holes. Remove the enclosure. Drill the lower holes and install two fasteners.
Place the enclosure's upper keyholes over the two upper screws.
Install the two lower screws and make sure to tighten all screws
(Enclosure Dimensions, pgs. 11-12).
2. Sav4D, Sav9D, and Sav18D:
Connect unswitched AC power 115VAC, 60Hz or 230VAC, 50Hz to
the removable terminals marked [L, G, N] (Fig. 1, pg. 2).
- 2 -
Sav Reference Chart:
12VDC 4
12VDC 9
12VDC 18
12VDC 18
12VDC 36

Installation Instructions:

Overview:
2.5A* 1.5A 0.75A
2.5A* 1.5A 0.75A
2.5A* 1.5A 0.75A
2.5A* 3A 1.5A
2.5A* 3A 1.5A

Specifications:

Features (cont'd):
• Field installable 3-wire line cord
with integral strain relief.
• Ease of installation saves time and
eliminates costly labor.
Enclosure Dimensions (H x W x D approx.):
• Sav4D, Sav9D, and Sav18D:
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
• Sav182D and Sav36D:
13.5" x 13" x 3.25"
(342.9mm x 330.2mm x 82.6mm).
Agency UL Listings and
Listings File Numbers
UL Listed for Commercial
CCTV Equipment
(UL 2044).
CUL Listed - CAN/CSA
C22.2 No. 1-04, Audio,
Video and Similar
Electronic Equipment.
Sav4/9/18/182/36D Installation Guide
Fig. 1
