Vehicle connections

The connection information listed below is specific to the 2005 Lincoln LS. Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan No Connection
H1/2 Tan/Black No Connection
H1/3 Orange/Brown (Data) HS CAN Low [4]
H1/4 Orange/Green (Data) HS CAN High [4]
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black (Data) RX
H1/8 Yellow/Black (Data) TX
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Factory Alarm Arm Output
H2/2 Blue/White (-) Ground When Running (Status) Output
H2/3 Dk. Green/Black (-) Door Lock Output
H2/4 Red/White (-) Trunk/Hatch Release Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
H2/7 White (+) AUX 1 Output [4]
H2/8 Violet/Black (+) AUX 2 Output
H2/9 Dk. Blue/Black (-) Door Unlock Output
H2/10 Lt. Blue/Black (-) Factory Alarm Disarm Output (flashed for
double pulse)
H2/11 Brown/Red (+) Siren Output [2]
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet (+) Door Input
H2/14 Brown (+) Brake Input
H2/15 White/Blue (-) Activation Input
H2/16 Red/Blue (-) Headlight Detection
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Input [5]
7 933.FORD1 4.17.193.2 2005 Lincoln LS
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 14
Not present in all vehicles.
OBD-Data Link Connector, black 16 pin plug, pin 6
Not present in all vehicles.
No Connection
No Connection
PATS Transceiver on ignition switch, green 4 pin plug, pin 4
PATS Transceiver on ignition switch, green 4 pin plug, pin 3
Connects To
Wire Location
Driver Door Module, 20 pin plug, pin 16
No Connection
No Connection
FEM in driver kick, 26 pin plug, pin 4
No Connection
No Connection
No Connection
No Connection
No Connection
Driver Door Module, 20 pin plug, pin 17
No Connection
No Connection
brake pedal switch
No Connection
No Connection
No Connection
No Connection
REM in trunk, above battery, 12 pin plug, pin 11
(+/-) Wire Color Connection
Data Blue/Red Mandatory
Data Gray/Red Optional
Data Gray/Red Remote Start
Only
Data White/Red Remote Start
Only
(+/-) Wire Color Connection
- black/blue Mandatory
- white Mandatory
doubl black/white Mandatory
e -
Security Only
+ orange/blue Remote Start
Only
- black/blue Security Only
