1-Key programming using Key2GO

Please ensure that the vehicle is in a safe location, and cannot move forward during
1
programming. For vehicles equipped with a manual transmission, make sure the
gearshift lever is in the neutral position.
DS3+: Connect the 12-pin main power harness to the DS3+ module FIRST.
Wait until the LED turns ON solid red before proceeding to the next step.
2
DS4+: Connect the 12-pin main power harness to the DS4+ module FIRST.
The LED will turn ON solid Blue for 1 second to confirm Bluetooth communication.
Wait until the LED turns ON solid red before proceeding to the next step.
Connect the remaining harnesses to the module.
Note: To skip the transponder programming and use convenience features only, press
3
the programming button 5 times. When the LED turns ON solid orange, proceed to the
next step. (This feature can only be used with vehicles that are NOT equipped with an
OEM alarm.)
Insert the key and turn the ignition ON and OFF twice. The LED now flashes orange.
4
If the transponder programming was skipped, the LED turns ON solid orange for 3
seconds then shuts OFF. The programming is now complete.
Remove the module from the vehicle, and reconnect it to your computer. The web site
5
will automatically recognize that you are moving onto the second phase of the
programming sequence.
6
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid
7
green for 3 seconds, once the module is successfully programmed.
Pair remotes (if applicable). For information on how to pair a specific remote, please
8
refer to its corresponding owner documentation, which can be found inside the product
packaging of the complete system or on www.directechs.com.*
DATA Tach: Firmware using DATA Tach, the tachometer is preprogrammed for the
vehicle and no further action is required. For instructions on how to adjust tach or use
Virtual tach, refer to "Initialize Virtual Tach" (not needed with hardwired or data tach
applications).
9
Hardwire Tach: Firmware using the Violet/White Hardwire Tach input will require
programming. For instructions on how to program or adjust tach or use Virtual tach,
refer to "Initialize Virtual Tach" (not needed with hardwired or data tach applications).
* Your aftermarket remote may differ from the model shown in the illustrations.
You have successfully completed the module programming sequence.
