Directechs DS3+ Installation Manual page 8

Module
Conn./Pin Color Description
H2/20 Green (-) Door Input (4 doors) [5]
H2/21 Gray (-) Hood Input [1]
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. No Connection
H3/2 Blue/Red Relay N.O. (+) 12 Volt Input
H3/3 Blue Relay COM (+) Accessory 3 Output
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM (-) Parking Light Output [6]
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. (-) Ground
H3/8 Lt. Green Relay COM RAP Off Interrupt (conn. side)
H3/9 Lt. Green/White Relay N.C. RAP Off Interrupt (vehicle side)
H3/10 Black (-) Ground
H3/11 White Relay COM (-) Parking Light Output [6]
H3/12 Red (+) 12 Volt Input
8 933.FORD1 4.17.193.2 2005 Lincoln LS
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
FEM in driver kick, 20 pin plug, pin 8
FEM in driver kick, 26 pin plug, pin 15
REM in trunk, above battery, 26 pin plug, pin 16
REM in trunk, above battery, 20 pin plug, pin 17
For vehicle door trigger inputs, use Tech Tip 1921, refer to
Directwire for more information.
FEM in driver kick, 12 pin plug, pin 3
any ignition coil or fuel injector
Connects To
Wire Location
No Connection
Ignition Switch, black 8 pin plug, pins 1, 7
Ignition Switch, black 8 pin plug, pin 4
No Connection
Refer to 'Locating components in the vehicle' - Parking Light
wiring.
Must use a 2 relays.
Must use a 1800 Ohm resistor.
10A fuse to 12V.
Must use (2) 1N4002 diodes or larger.
Ignition Switch, black 8 pin plug, pins 1, 7
FEM in driver kick, 20 pin plug, pin 8
FEM in driver kick, 20 pin plug, pin 8
Refer to 'Locating components in the vehicle' - Parking Light
wiring.
Must use 2 relays.
Must use a 1800 Ohm resistor.
10A fuse to 12V.
Must use (2) 1N4002 diodes or larger.
Ignition Switch, black 8 pin plug, pins 1, 7
(+/-) Wire Color Connection
- black/yellow Security Only
N.C. black/blue
- black/orange
N.C. black/green
-
N.C.
-
N.C.
- white
N.C.
ac brown or brown/stripe Remote Start
Only
(+/-) Wire Color Connection
+ Red (x2) (common 20A) Remote Start
Only
+ Yellow Remote Start
Only
see Tech Doc 1095 Mandatory
+ Red (x2) (common 20A) Mandatory
(chassis ground) Mandatory
- N.C. black/yellow Remote Start
Only
- N.C. black/yellow Remote Start
Only
(chassis ground) Mandatory
see Tech Doc 1095 Mandatory
+ Red (x2) (common 20A) Mandatory
