Removing Acl Binding - 3Com 3CBLSG48 User Manual

Removing ACL
Binding
The ACL Binding Remove Page allows the network administrator to
remove user-defined ACLs from a selected interface.
The monitor user has no access to this page.
To remove ACL Binding:
1 Click Device > ACL > ACL Binding > Remove. The ACL Binding
Remove Page opens.
Figure  ACL Binding Remove Page
The ACL Binding Remove Page contains the following fields:
Interface — Displays the port interface to which the ACL is
bound.
ACL Name — Displays the name of ACL to be removed from the
selected port.
 Select an ACL to be removed.
 Click Apply. The selected ACLs are removed, and the device is
updated.
C 4: M D
HAPTER ANAGING EVICE
S
9
ECURITY
