Vancouver
36. Drill two 1 3/4 in (45 mm) holes in the map
light housing as indicated.
NOTE: The map light is shown installed for
clarity. Do not install the dome light at this
time.
37.Connect the wiring connector and install the
control panel (68) using four screws (20).
38.Make the following connections at the basic
and electrical boards. Refer to pages 28 and
29 for more information.
• ground jumper (60)
• positive jumper (62)
• board-to-board jumper (61)
• chassis ground cable (63)
