Webasto T70 Installation Instructions Manual

Webasto T70 Installation Instructions Manual

Park heating with remote control for bmw 3 series models with m47 engine
Hide thumbs Also See for T70:

Advertisement

Table of Contents

See also: Instruction and Installation Manual
Teile und Zubehör – Einbauanleitung
Aufrüstungssatz Standheizung mit Fernbedienung T70
BMW 3er-Reihe, Limousine (E46/4) Linkslenker
Modelle mit M47 Motor bis 9.99
Park Heating with Remote Control T70 kit
BMW 3 Series, saloon (E 46/4) left-hand drive
Models with M47 engine to 9.99
Kit de deuxième monte "chauffage auxiliaire" avec télécommande T70
BMW Série 3, berline (E 46/4) direction à gauche
Modèles à moteur M47 jusqu'à 9.99
Uitbreidingsset parkeerverwarming met afstandsbediening T70
BMW 3-serie, sedan (E 46/4), linksgestuurd model
Modellen met M47 motor tot 9/99
Monteringssats kupévärmare med fjärrkontroll T70
BMW 3-serie, sedan (E 46/4) vänsterstyrd bil
Modell med M47 motor t.o.m. 9/99
Nachrüst-/Einbausatz-Nr.: 82 30 0 020 941
EBA Nr.: 01 29 0 021 305
Stand: 05.2000
F 46 0006 R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Webasto T70

Summary of Contents for Webasto T70

  • Page 1 Park Heating with Remote Control T70 kit BMW 3 Series, saloon (E 46/4) left-hand drive Models with M47 engine to 9.99 Kit de deuxième monte "chauffage auxiliaire" avec télécommande T70 BMW Série 3, berline (E 46/4) direction à gauche Modèles à moteur M47 jusqu'à 9.99...
  • Page 2 BMW Parts and Accessories Installation Instructions F 46 0006 R Park Heating with Remote Control T70 kit BMW 3 Series, saloon (E 46/4) left-hand drive Models with M47 engine to 9.99 (Only for use within the BMW trading organisation) Technical knowledge is required.

  • Page 3: Table Of Contents

    Contents Chapter Page 1. Necessary preparatory work on the vehicle ..............24 2. Installation and cabling diagram ..................25 3. Connection diagram ....................26 4. Check state of the art of the model and if necessary change plug connector and blower regulator (only vehicles with IHKA automatic heating and air conditioning to 9.98) ........................27 5.
  • Page 4 General notes In the course of further development it may happen that connections and/or pin assignments change. The current test instructions should always be used for installation purposes. Should specified pin spaces be assigned, bridges, double crimping or parallel connections will have to be made.

  • Page 5: Necessary Preparatory Work On The Vehicle

    Preparatory work TIS AW no. Carry out short test Disconnect battery 12 00 ... Completely dismantle glove box 51 16 360 + 51 45 030 Dismantle A-pillar trim panel on right 51 43 201 Dismantle sun visor on right 51 16 080 Unclip heater/air conditioner operating unit 64 11 749 / 64 11 750 In this TIS operation, only the relevant work steps for this disassembly must be carried out.

  • Page 6: Installation And Cabling Diagram

    2. Installation and cabling diagram F 46 0012 2W Antenna Timer (optional) Connection blower activation Receiver Park heating relay and fuse holder Supplementary/park heating unit EN/25 Retrofit/Installation Kit no. 82 30 0 020 941 Date: 05.2000 Installation Instructions no. 01 29 0 021 305...

  • Page 7: Connection Diagram

    3. Connection diagram F 46 0351 M Code designation/ Cable colour/ Connection point/installation Item Designation cross-section location in vehicle 1-pole socket housing ––––– Mating connector to F Socket contact ––––– for socket housing (1) 1-pole pin housing ––––– Mating connector to G Pin contact –––––...

  • Page 8: Check State Of The Art Of The Model And If Necessary Change Plug Connector And Blower Regulator (Only Vehicles With Ihka Automatic Heating And Air Conditioning To 9.98)

    4. Check state of the art of the model and if necessary change bridging connector and blower regulator (only vehicles with IHKA (automatic heating and air conditioning) to 9.98) If at plug-in place (1) a relay instead of plug connector (gold-yellow) is fitted, this will have to be replaced with a plug connector (gold-yellow).

  • Page 9: Install Park Heating Wiring Harness And Connect It

    5. Install park heating wiring harness and connect it Only vehicles with IHR (integrated heating control) to 9.98: Fuse 1A (2) must be plugged on to fuse holder A1* (cable cross-section 0.5 mm Fuse 25A (1) must be plugged on to fuse holder A2* (cable cross-section 2.5 mm Only vehicles with IHKA (automatic heating and air conditioning) from start of production...
  • Page 10 Install park heating wiring harness and connect it Take off black plastic cover (1) from connector X13020. Undo hexagon nut M8 (2). Connect branch cable B, terminal 30 (3), cable colour red, to connector X13020. F 46 0013 R Pull out joint connector housing from the joint connector box.

  • Page 11: Install Antenna And Receiver

    6. Install antenna and receiver Clean windscreen in the adhesion area. When sticking on the antenna, the windscreen should be at a temperature of at least +20 °C. It is essential that the antenna lead is installed in such a way that the ITS head air bag is not handicapped when it unfolds.

  • Page 12: Install Timer (Optional)

    Install timer (optional) If no timer is to be fitted, branch cable E (1) should be tied back to the wiring harness. Install branch cable E (1) to the notch (2) by the side of the radio slot on the left. F 46 0016 R Stick the supplied drilling template on the finisher (1).

  • Page 13: Coding

    8. Coding In vehicles from 9.98 with IHKA (automatic heating and air conditioning), the IHKA control unit and the control unit of the supplementary heater have to be re-coded. In vehicles with IHR (integrated heating control), no coding has to be carried out. The coding version current at the time should be used for coding purposes.

  • Page 14: Making The Hand-Held Transmitter Operational

    9. Making the hand-held transmitter operational Place batteries in the hand-held transmitter Open battery compartment lid (1) in the direction of the arrow. Place two standard batteries (type MN21) (2) as shown in the hand-held transmitter (3) and close the battery compartment again. Please dispose of used batteries properly! F 46 0169 M Check batteries in the hand-held transmitter...

  • Page 15: Pre-Settings

    10. Pre-settings To arrive at an optimal de-icing action, there are one or two pre-settings to make on the hea- ter or air conditioner operating unit before swit- ching off the ignition. The operating mode "Park ventilation" is not possible with this retrofit. Only vehicles with IHKR (integrated heater and air conditioner control) and IHR (integrated heater control)

  • Page 16: Operating With Hand-Held Transmitter

    11. Operating with hand-held transmitter If the distance between hand-held transmitter (2) and the antenna is less than 2 metres, this may bring about an overloading and the park heating cannot be switched on or off. Set the duration for which the park heating is to operate with the hand-held transmitter (2): The park heating operating time can be set with the hand-held transmitter (2) in steps of 10...
  • Page 17 11. Operating with hand-held transmitter Switch on park heating with hand-held transmitter (2): The pre-settings (Chapter 10) have to be made before leaving the vehicle. • Hold the hand-held transmitter (2) with the antenna vertical and press the ON button (3) for longer than 2 seconds.

  • Page 18: Operating With Timer (Optional)

    12. Operating with timer (optional) Switch on park heating: manually: Press button Heat immediately automatically: by pre-programming start of heating On-indicator: (5) and orange display Heating On indicator light illuminate during the whole of the heating period. Switch off park heating: manually: Press button Heat immediately F 46 0175 M...
  • Page 19 12. Operating with timer (optional) Program start of heating: It is possible to program three different switch-on times. Press button (2) ) once and program the first switch-on time according to the following plan. The display (6) shows “-:--” or a time. Press the Forwards (1) or Back (3) button...

  • Page 20: Circuit Diagram For Vehicles With Ihr (Integrated Heating Control) To 9.98

    13. Circuit diagram for vehicles with IHR (integrated heating control) to 9.98 EN/39 Retrofit/Installation Kit no. 82 30 0 020 941 Date: 05.2000 Installation Instructions no. 01 29 0 021 305...
  • Page 21 Key to circuit diagram for vehicles with IHR (integrated heating control) to 9.98 Fuse holder for park heating behind glove box Fuse holder for park heating behind glove box Control unit, park heating A128 Receiver for remote control 1A fuse for remote control 25A fuse for blower control K450 Park heating relay behind glove box...

  • Page 22: Circuit Diagram For Vehicles With Ihka (Automatic Heating And Air Conditioning)

    14. Circuit diagram for vehicles with IHKA (automatic heating and air conditioning) from start of production and vehicles with IHR from 9.98 EN/41 Retrofit/Installation Kit no. 82 30 0 020 941 Date: 05.2000 Installation Instructions no. 01 29 0 021 305...
  • Page 23 Key to circuit diagram for vehicles with IHKA (automatic heating and air conditioning) from start of production and vehicles with IHR from 9.98 Fuse holder for park heating behind glove box Fuse holder for park heating behind glove box Heater or air conditioner operating unit Control unit, park heating Fuse holder II A128...
