Vancouver
22.Using the #6 90º fitting (26), connect the
high-pressure hose to the Vancouver
assembly. Tighten the TXV plate.
NOTE: Trim the drain hose at a 45º angle,
away from the direction of travel.
23.Using the drain t (32) and the drain hose (4),
connect the two drain ports together. Route
the drain hose through the headliner, down
the body in either rear corner and through an
existing hole in the body. Trim the drain hose
about 1 inch (25 mm) below the body.
26
Ford Transit
