▲ Overview of Control Panel
1. LCD screen operate panel
2. Pressure indicator
3. Safety indicator
4. 5-pin XLR Socket
5. 110V/220V Power Socket
6. Auto-reset Fuse
7. Fuel Input Quick Coupler (G1/4, ISO7241B
8. Safety Lock
9. ON/OFF Switch
10. 3-pin XLR Socket
11. DC 9V-60V fireworks igniter signal port
▲ Operation Panel
4
