Directed Directechs DS4+ Installation Manual page 50

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
T-Harness compatibility
Vehicle
Toyota CH-R (H Key)
Function
CH-R (H Key) 2018
HS CAN 1 High
HS CAN 1 Low
SIL
HS CAN 2 High
HS CAN 2 Low
RDA
Autolights
Parking Lights
Accessory
Ignition
Starter
12V
SIL Interrupt
50
Year T-Harness
2018 THTON3
Wire Information
Color
Red
White
Lt. Blue
Brown
White
Lt. Green
White
Yellow
Green
Gray
Violet
Black/White
Lt. Blue
Pin Polarity Location
6 Data OBDll
14 Data OBDll
7 Data OBDll
3 Data Steering sensor connector.
2 Data Steering sensor connector.
4 Data Body ECU connector.
20 Cut Headlight switch.
18 (-) Headlight switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
6 (+) Ignition switch.
1 (+) Driver kick panel.
35 Cut Driver kick Panel.
Connector Information
Color Pins
White 16
White 16
White 16
Blue
Blue
White 30
White 20
White 20
White
White
White
White
White 62
© 2017-05-29 Directed. All rights reserved.
Ref.
A
A
A
5 B
5 B
C
D
D
8 E
8 E
8 E
1 F
G
DS4+ TL10
