Type 12 - Directed Directechs DS4+ Installation Manual

Type 12

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 44 for important information on this installation.
Body ECU
Connector
RDA: Pink, pin 16
6 5 4
16
18 17 15 14
30 29 28 27 26
Dash Fuse Box
(white conn.)
36 27
12
35 26
11
34 25
Cut
33 24
10
32
23
9
31 22
SIL:
30 21
8
Blue,
29 20
pin 32
7
28 19
Ignition Connector
18 6
17 5
16 4
15 3
14 2
13 1
Refer to the Vehicle Wiring
Reference Information for wire
and connector details.
43
Steering Sensor
3 2
5 4 1
HS CAN 2 High:
HS CAN 2 Low:
Pink, pin 3
White, pin 2
Body ECU
3 2 1
Connector
13 12 11 10 9 8 7
(middle connector
left side
23 19
25 24 22 21 20
of steering column)
(-) Trunk Release: Blue, pin 23
(+) 12V: Black, pin 1
Cut
Autolight: Violet
or Red, pin 19
1
10 9 8 7
Dash Fuse Box
19 18 17
20
(white conn.)
Headlight Switch
4 3 2 1
8 7 6 5
HS CAN 1 High: SIL Data: Black, pin 7
Gray, pin 6
1
9
HS CAN 1 Low: White, pin 14
HS CAN 2 Low: Orange/Brown: 3
HS CAN 2 High: Orange/Green: 4
(-) Trunk Release Output: Red/White: 4
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
SIL Interrupt (conn. side): Blue/White: 1
SIL Interrupt (veh. side): Blue: 3
Autolight Interrupt (veh. side): Lt. Green: 8
Autolight Interrupt (conn. side): Lt. Green/White: 9
(+/-) Flex Output: Pink/White: 4
6 5 4 3 2 1
Starter Disable (key side): Green: 6
16 15 14 13 12 11
(+) 12V Starter Output (starter side): Violet: 7
(+) 12V Accessory Output: Orange: 8
(+) Ignition Input/Ouput: Pink: 10
Diagnostic
8
Connector OBDII
16
HS CAN 1 Low: Tan: 1
HS CAN 1 High: Tan/Black: 2
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
(+) 12V Input: Red/Black: 2
(+) 12V Ignition Input: Red: 5
Slide
(+/-) Flex Input: Red/White: 9
to open
It is important to check that the
fuses are positioned correctly.
DS4
DS4
DS4+
DS4+ TL10
