Type 15 With T-Harness Thton4) - Directed Directechs DS4+ Installation Manual

Type 15 with T-Harness THTON4)

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 53 for important information on this installation.
Body ECU
Connector
OR
BODY ECU
6
18
30
SIL: Yellow, pin 3
11 10
9 8 7 6 5 4
18 1716 15 1413
Tire Pressure Warning ECU
(white conn. in passenger kick panel)
51
1 8
9 16
Diagnostic Connector OBDII
FUSES
RDA: Blue, pin 16
5 4 3 2 1
17 16 15 14 13 12 11 10 9 8 7
29 28 27 26 25 24 23 22 21 20 19
Body ECU Connector
(middle or underside conn. of ECU)
Cut
Autolight Interrupt (veh. side): Lt. Green
2 1
3
Cut
12
Autolight Interrupt (conn. side): Lt. Green/White
Autolight: Green, pin 20
10 9 8 7 6 5 4 3 2 1
20 19 18 17 16 15 14 13 12 11
Headlight Switch
THTON4
(optional T-Harness)
Refer to the "Vehicle wiring reference
chart" for more specific T-harness
compatibility.
RDA: Orange/Black
Siren
Hood Pin
SIL Interrupt (veh. side): Blue
SIL Interrupt (conn. side): Blue/White
Ignition Connector
8-pin White
Connector
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
12-pin Black
Proper Fuse
Connector
Positioning
10-pin White
Connector
Slide
to open
It is important to check that the
fuses are positioned correctly.
DS4
DS4
DS4+
DS4+ TL10
