0076 0076 1 E_BaseMet_Wind_Direc
tion
0077 0077 1 E_BaseMet_Rain
0078 0078 1 E_BaseMet_Snow
0079 0079 1 E_BaseMet_PPT_Type int16
0080 0080 1 E_BaseMet_Electric_Fie
ld
0081 0081 1 E_BaseMet_Surface_W
etness
0082 0082 1 E_BaseMet_Soil_Moistu
re
0083 0083 1 C_SunSpec_DID
0084 0084 1 C_Sunspec_Length
0085 0085 1 E_Irradiance_Global_H
orizontal_1
0086 0086 1 E_Irradiance_Plane-of-
Array_1
0087 0087 1 E_Irradiance_Diffuse_1 uint16
0088 0088 1 E_Irradiance_Direct_1
0089 0089 1 E_Irradiance_Other_1
0090 0090 1 C_SunSpec_DID
0091 0091 1 C_Sunspec_Length
0092 0092 1 E_BOM_Temp_1
0093 0093 1 E_BOM_Temp_2
0094 0094 1 EndOfSunspecBlock
0095 0095 1 C_Sunspec_Length
0200 0200 1 Modbus Id - Write
Register
Changing the Modbus Device Address
The Modbus device can be changed using either the MBID command or directly through
Modbus. Refer to the Command Mode instructions to set the address using the command
mode.
Modbus register 40200 contains the unsigned 16-bit address. Writing to this register will
update the device's Modbus address. The write request will be acknowledged but will
change immediately after the response has been issued. The valid address range is 1
through 255. Write requests outside this range will not update the address. The address is
stored in flash memory and will remain in affect permanently or until it is changed again.
int16 Degrees
int16 Inches
int16 Inches
Inches N/A
int16 V/m
int16 kOhms
int16 %
int16 N/A
int16 N/A
uint16 W/m²
uint16 W/m²
W/m²
uint16 W/m²
uint16 W/m²
int16 N/A
int16 N/A
int16 °C
int16 °C
uint16 N/A N/A
uint16 N/A
int16 N/A N/A
- 11 -
0 N/A Wind Direction
0 N/A Rainfall
0 N/A Snowfall since last poll
N/A Precipitation Type (WMO 4680
SYNOP code reference)
0 N/A Electric Field
0 N/A Surface Wetness
0 N/A Soil Moisture
0 302 Well-known value. Uniquely
identifies this as a SunSpec
Irradiance Model
0 5 Variable length model block
=(5*n), where n=number of
sensors blocks
0 Measured Global Horizontal Irradiance
0 N/A Plane-of-Array Irradiance
0 N/A Diffuse Irradiance
0 N/A Direct Irradiance
0 N/A Some other type Irradiance
0 303 Well-known value. Uniquely
identifies this as a SunSpec
Back of Module Temperature
Model
0 2 Variable length model block
=(5*n), where n=number of
sensors blocks
-1 Measured Back of module temperature
-1 Measured Back of module temperature
0xFFFF End of SunSpec Block
0 0 Terminate length, zero
60 Modbus device address, write
register
