D Receiver - Icom ID-52A Basic Manual

9
SPECIFICATIONS
D General
• Power supply:
• Current drain (at 7.4 V DC):
Transmit (at 5 W)
Receive (Maximum output, 8 Ω load)
FM/FM-N
DV
• Antenna connector:
• Dimensions:
(projections not included) 2.4 (W) × 4.8 (H) × 1.2 (D) inches
• Weight (approximate):

D Receiver

• Receive system:
• Intermediate frequencies:
A band
B band
• Sensitivity:
Ham band
Outside Ham band
Band
BC band
A band
B band
* "WFM" is for only BC band. "FM" and "FM-N" is for only A/B band.
1
* "AM-N" is for only 108.000 MHz ~ 143.995 MHz.
2
• Audio output power:
Internal speaker
External speaker
• Selectivity:
FM
FM-N/DV
35
10.0 ~ 16.0 V DC for external DC power
7.4 V DC specified Icom's battery pack
5.5 V DC specified Icom's battery case
Less than 2.5 A
Less than 400 mA
Less than 450 mA
SMA (50 Ω)
61.1 (W) × 121.6 (H) × 29.7 (D) mm,
295 g, 10.4 oz (Including battery pack and antenna)
Double Conversion Superheterodyne
1st IF 58.05 MHz, 2nd IF 450 kHz
1st IF 57.15 MHz, 2nd IF 450 kHz
FM/FM-N Less than 0.18 μV (at 12 dB SINAD)
DV Less than 0.2 μV (at 1% BER)
Frequency range
(MHz)
76.000 ~ 108.000
108.000 ~ 136.991
137.000 ~ 142.000
142.005 ~ 148.000
148.005 ~ 174.000
225.000 ~ 259.995
260.000 ~ 354.995
355.000 ~ 374.995
375.000 ~ 399.995
400.000 ~ 479.000
137.000 ~ 148.000
148.005 ~ 174.000
375.000 ~ 399.995
400.000 ~ 479.000
More than 0.75 W at 10% distortion into an 8 Ω load
More than 0.2 W at 10% distortion into an 8 Ω load
More than 55 dB
More than 50 dB
FM/FM-N/WFM*
1
(12 dB SINAD)
Less than 1 μV
–
Less than 0.18 μV
Less than 0.18 μV
Less than 0.32 μV
Less than 0.56 μV
Less than 0.32 μV
Less than 0.5 μV
Less than 0.5 μV
Less than 0.32 μV
Less than 0.18 μV
Less than 0.32 μV
Less than 0.5 μV
Less than 0.32 μV
AM/AM-N*
2
(10dB S/N)
–
Less than 1 μV
Less than 1 μV
–
–
Less than 1.8 μV
Less than 1 μV
Less than 1.8 μV
–
–
–
–
–
–
