CONTENTS 1. Safety Instructions ....................2 2. Technical Specifications ..................4 3. Control Panel ......................5 4. How To Set The Unit ....................6 4.1 Main Function ....................6 4.2 Home Position Adjustment................7 5. Control By Universal DMX Controller ..............13 5.1 DMX512 Connection ..................
1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
Page 4
DO NOT touch any wire during operation as there might be a hazard of electric shock. Avoid power wires together twist other cables. The minimum distance between light output and the illuminated surface must be more than 0.5 meters.
1. DISPLAY: To show the various menus and the selected function 2. Button: MENU To enter into move backward or leave the menu To go backward to move up in the menu DOWN To go forward to move down in the menu ENTER To perform the desired functions 3.
1-507(6CH) 1-500(13CH) 1-495(18CH) 1-475(38CH) 1-387(112CH) DMX Address 1-496(16CH) 1-480(32CH) 1-448(64CH) 13CH 18CH 38CH 112CH DMX Channel Mode DMX Settings 16CH 32CH 64CH BlackOut Hold No DMX Status Manual Linear Square law Dimmer Curve Inv SQ law S Curve Fast Fixture Settings Dimmer Speed Smooth Main Menu...
Page 9
DMX Settings To select DMX Settings, press the ENTER button to confirm, use the UP/DOWN button to select DMX Address, DMX Channel Mode, No DMX Status or View DMX Value. DMX Address To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust the address from 001 to 507/387, press the ENTER button to store.
Page 10
Linearity: As the DMX value increases, the increase in light intensity tends to be linear Square Rate: when the light intensity is controlled at a low value, the lines are finer, and at high values, the lines are thicker; inverse square rate: when the light intensity is controlled at a low value, the lines are thicker, and when the light intensity is controlled at a high value, the lines are thinner;...
Page 11
Display Inversion To select Display Inversion, press the ENTER button to confirm, the current mode will be displayed on the display, use the UP/DOWN button to select: No or Yes, press the ENTER button to save. Press the MENU button to return to the previous menu or wait one minute to automatically exit the menu mode.
Page 12
Manual Test To select Manual Test, press the ENTER button to confirm, the present channel will show on the display, use the UP/DOWN button to select channel, press the ENTER button to confirm, then use the UP/DOWN button to adjust the value, press the ENTER button to store, the fixture will run as the channel value indicates.
Page 13
display, press the MENU button to exit. Fan State To select Fan State , press the ENTER button to confirm, firmware version will show on the display, press the MENU button back to exit. Firmware Version To select Firmware Version, press the ENTER button to confirm, firmware version will show on the display, press the MENU button back to exit.
RDM FUNCTIONS Select the MANUFACTURER menu to display the manufacturer of the fixture. Select the SOFTWARE VERSION menu and the program version number of the fixture will be displayed. Select the DMX START ADDRESS menu to change the DMX 512 address (001-507). Select the DEVICE MODEL DESCRIPTION menu to display the model of the fixture.
distort the signal and shut down the system. 3. The DMX output and input connectors are pass-through to maintain the DMX circuit, when one of the units’ power is disconnected. 4. Each lighting unit needs to have a DMX address to receive the data by the controller. The address number is between1-508.
5.3 DMX512 Configuration Please refer to below configurations to control the fixtures Attentions: 1. The unit will maintain the last condition until reset if you cut-off the DMX signal. 2. For the channel Function, keep the value for about Five seconds, then the corresponding function will take into effect.
Page 17
18channel value function 000-255 000-255 Green 000-255 Blue 000-255 Color Dimmer Intensity:Intensity 000-255 0 to 100% 000-255 Dimmer Fine: 0 to 100% 0-255 Strobe Duration Blackout 7-255 Strobe Rate No effect 6-50 Ramp up 51-100 Ramp down 101-150 Ramp up-down 151-200 Lightning 201-255 Random Macro 0-22 No function 23-31 Macro1 … … 247-255 Macro26 0-255 Macro_Speed Dimmer Intensity:Intensity...
LED Zoning map: 6/13/18CH 16CH 32CH 64CH 112CH 6. rror Information LED Fan Error Check if the fan is not running. Check if the fan leads are installed in place or disconnected. Check if the fan is damaged. Check if there are other interference items in the fan operating range. Check if the fan circuit on the motherboard breaks down.
7. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power. 2. Measure the mains voltage on the main connector. 3.
