10W LED COLOR SPOT
LED-PS10D RGBW

User Manual

Professional Entertainment Technology

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED-PS10D RGBW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ACME LED-PS10D RGBW

  • Page 1: User Manual

    10W LED COLOR SPOT LED-PS10D RGBW User Manual Professional Entertainment Technology...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instruction 2. Technical Specification 3. Installation 4. How to Control the Unit 4.1 Control Panel 4.2 Master/Slave operation 4.2 Easy controller 4.4 Universal DMX controller 5. DMX 512 Configuration 6. DMX 512 Connection 7. Trouble Shooting 8.
  • Page 3: Safety Instruction

    1. Safety Instruction Please read the instruction carefully which including important information about the installation, WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit.
  • Page 4: Installation

    Voltage: AC 100-240V~50/60Hz LED: 1 x 10W quad-color LED, 50,000 hrs rated Power Consumption: 14.9W Dimension: 187 x 156 x 115 mm Weight: 2.0kg 3. Installation The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating.
  • Page 5: Master/Slave Operation

    ○ Hanging bracket: With 2 knobs on both sides to fasten the unit and a mounting hole to fix a mounting hook ○ Optical Lens: Turn the lens to change the focus and obtain sharp gobos ○ DIP Switches: Set the different function settings ○...
  • Page 6: Easy Controller

    4.3 Easy Controller (by CA-8/CA-9/CA-9RTX) The easy remote control is used only in master/slave mode. By connecting to the 4-pin jack of the first unit, you will find that the remote controller on the first unit will control all the other units for Stand by, Function and Mode selection Blackout Blackout the unit Strobe...
  • Page 7 DMX 512 Address Chart: Dip-switch Channel Value mode Dip switch 10 OFF Channel 1:dip / on: #1 (=1) Channel 2:dip / on: #3 (=4) Channel 3:dip / on: #1,#2, #3 (1+2+4=7) Channel 4:dip / on: #2, #4 (2+8=10) Dip switch 10 ON Channel 1:dip / on: #1 (=1) Channel 2:dip / on:, #1, #3 (1+4=5) Channel 3:dip / on: #1, #4 (1+8=9)
  • Page 8: Dmx 512 Configuration

    5. DMX 512 Configuration...
  • Page 9: Dmx 512 Connection

    6. DMX 512 Connection The DMX 512 is widely used in intelligent lightings and with a maximum of 512 channels. 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable.
  • Page 10: Troubleshooting

    7. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The fixture does not work, no light 11. Check the connection of power and main fuse. 12. Measure the mains voltage on the main connector. B.
  • Page 11: Fixture Cleaning

    8. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
  • Page 12 Широкий ассортимент оборудования ACME на www.maxlight.ru Innovation, Quality, Performance...
