- Page 1 TABLE OF CONTENTS 1. Safety Instructions 2. Technical Specifications VENOM 3. Installation 4. How to set the unit 5. How to control the unit 6. DMX 512 Configuration 7. DMX 512 Connections 8. Troubleshooting 9. Fixture Cleaning LED-460 User Manual Please read the instructions carefully before use...
- Page 2 Safety Introductions 2. Technical Specifications Featuring 6 high-power 3W Tri-color LEDs. — Please read the instructions carefully which includes important Each color of R, G, B, can be controlled individually. — information about the installation, operation and maintenance. WARNING — DMX 3/18 channels switchable.
- Page 3 4. How toset the unit 4.2 Main Function 4.1Rear Panel To select any functions, press MENU button until the required one is shown on the display. Select the function by ENTER button and the display will blink. Use DOWN and UP button to change the mode.
- Page 4 press the MENU button DMX 512 Address Setting Blackout mode Press the MENU button up to when the is shown on the display. Pressing the ENTER button and the display will blink. Use the DOWN and UP button to change the DMX Press the MENU button up to when the is shown on the display.
- Page 5 functions press the MENU button. 5.2 Easy Controller (by CA-8) The easy remote control is used only in master/slave mode. By 5. How To Control The Unit connecting to the 1/4” microphone jack of the first unit, you will find that You can operate the unit in three ways: the remote controller on the first unit will control all the other units for 1.
- Page 6 6. DMX512 Configuration 7. DMX512 Connections 3-CH modes: The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the 18-CH modes: fixture to the input of the next fixture.
- Page 7 8. Troubleshooting 9. Fixture Cleaning Following are a few common problems that may occur during operation. Here are some The cleaning of internal must be carried out periodically to optimize light output. Cleaning suggestions for easy troubleshooting: frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics.
- Page 8 EC - Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002; EN61000-4-4: 1995;...
