- Page 1 DYNAMIC SCAN User Manual Innovation, Quality, Performance Professional Entertainment Technology...
- Page 2 EC - Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002; EN61000-4-4: 1995;...
-
Page 3: Table Of Contents
of the fixture or the previous one. 4. Try to use another DMX controller. 5. Check if the DMX cables run near or run alongside to high voltage cables that may TABLE OF CONTENTS cause damage or interference to DMX interface circuit. C. - Page 4 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin 1. Safety Instruction adapter-cable. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 Please read the instruction carefully which including important ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug information about the installation, operation and maintenance.
- Page 5 5. DMX 512 Configuration 2. Technical Specification It can be operated by DMX512 control or can be used as an individual unit without controller. Please use a 3 pin XLR cable/plug when link in master/slave mode. Gobo wheel with 8 gobos plus open Smooth 0-100% dimming, and variable strobe speed.
- Page 6 4. How To Control The Unit 4.3 Easy Controller (by CA-8/CA-9/CA-9RTX) 4.1 Control Panel The easy remote control is used only in master/slave mode. By connecting to the 4-pin jack of the first unit, you will find that the remote controller on the first unit will control all the other units for Stand by, Function and Mode selection Stand by...
