Applicable Anybus Products; Requirements - HMS Anybus EtherNet/IP How To Configure

1.

Applicable Anybus products

Description
Anybus X-gateway
Anybus Communicator
Anybus-S Slave
Anybus-PCI
Anybus-CompactCom
Anybus-IC
2.

Requirements

Description
Rockwell PLC
PLC software
Anybus IPconfig tool
X-gateway Network Interface Addendum
X-gateway User Manual
Communicator User Manual
Slave Fieldbus Appendix
IC Fieldbus Appendix
CompactCom Network Interface Appendix
Power supply 24VDC
Configuration cables
Null modem cable (Supplied with the
Anybus X-gateway)
Saved: 2008-03-05
Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc
How to configure an EtherNetIP adapter with RSLogix 5000.doc
Name / Type
EtherNet/IP
EtherNet/IP
EtherNet/IP
EtherNet/IP
EtherNet/IP
EtherNet/IP
Name / Type
ControlLogix5000
RSLogix 5000
Anybus IPconfig
Anybus X-gateway Ethernet Slave
Interface, Network Interface
Addendum
X-gateway Generic User Manual
Anybus Communicator for Ethernet,
User Manual
Anybus-S EtherNet/IP, Fieldbus
Appendix
Anybus-IC EtherNet/IP, Fieldbus
Appendix
CompactCom EtherNet/IP, Network
Interface Appendix
n.a.
n.a.
n.a.
HMS Industrial Networks AB
SCM-7032-029
Rev 2.03
Version
n.a.
13.04.00
1.3.1.1
1.02
1.02
2.01
1.52
1.52
2.10
n.a
n.a.
n.a.
Page 4 (20)
