Applicable Anybus Products; Requirements - HMS Anybus CANopen Slave How To Configure

1

Applicable Anybus products

The following table specifies the relevant Anybus products for this document.
Description
Anybus X-gateway
Anybus Communicator
Anybus-Slave
Anybus-S Drive Profile
Anybus CompactCom
2

Requirements

The following equipment is needed to setup a successful configuration.
Description
Telemecanique Twido PLC
PLC software
Communicator configuration software
X-gateway terminal software
X-gateway Network Interface Addendum
X-gateway User Manual
Communicator User Manual
Slave Drive Profile Fieldbus Appendix
Slave Fieldbus Appendix
CompactCom Network Interface Appendix
Power supply 24VDC
Configuration cables
www.anybus.com
How to configure an Anybus CANopen slave module with TwidoSoft
Name / Type
CANopen
CANopen
CANopen
CANopen
CANopen
Name / Type
TWDLMDA20DRT
Twidosoft
ABC Config Tool
HyperTerminal or TeraTermPro
Anybus X-gateway CANopen Slave,
Network Interface Addendum
X-gateway Generic User Manual
Anybus Communicator for CANopen,
User Manual
Anybus-S CANopen Drive Profile,
Fieldbus Appendix
Anybus-S CANopen, Fieldbus
Appendix
Anybus-CompactCom CANopen,
Network Interface Appendix
n.a.
n.a.
HMS Industrial Networks AB
SCM-7032-042
Rev 1.01
Version
-
3.5
2.34
5.1, 2.3
1.02
1.11
2.51
1.00
2.04
2.01
n.a
n.a.
Page 4 (29)
