Technical Specifications - Altronix NetWay8GL Installation Manual

Fig. 2 - NetWay8GL
NetWay8GL - Front Panel
NetWay8GL - Rear Panel
2a OUT 1-8: Structured cable to PoE compliant cameras/edge devices.
2b IN 1-8: Structured cable to ethernet switch or video server.
2c LED(s) 1-8: Port status LEDs.
2d Reset: Restores unit to factory settings.
2e USB Port: For future use.
2f Ethernet: For future use.
2g IEC 320 Connector: 115/230VAC (grounded line cord included).
2h Built-in battery charger: Charges stand-by batteries for applications requiring back-up,
(optional rack mount battery enclosure available - RE2)
Parameter
No. of Ports
Output Power
Input Power Requirements
Indicators
Environmental Conditions
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 4 -
2a 2b

Technical Specifications:

Description
Eight (8) PoE/PoE+/Hi PoE Ports (10/100/1000 Mbps).
240W total.
115VAC, 60Hz, 3.25A or 230VAC, 50/60Hz, 2.0A.
Port Status LEDs.
Operating Ambient Temperature:
Relative Humidity:
Storage Temperature:
Operating Altitude:
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
2c
2g 2h
– 20ºC to 40ºC (– 4ºF to 104ºF).
85%, +/– 5%.
– 20ºC to 70ºC (– 4ºF to 158ºF).
– 304.8 to 3,048m.
NetWay8GL Installation Guide
2d
2e 2f
