Technical Specifications - Altronix NetWay8 Installation Manual

Fig. 5
NetWayXT/NetWayXTX
PoE Camera
NetWay8
Ethernet Switch
Parameter
No. of Ports
Input power requirements
Indicators
Environmental Conditions
Regulatory Compliance
NetWay8/NetWay16
NetWay8/NetWay16 Typical Application:
Extends Ethernet
100m (328 ft.)
I.T.E. 43KC
NetwayXT
Repeater
www.altronix.com
Power OUT IN

Technical Specifications:

Description
NetWay8 - Eight (8) Ports.
NetWay16 - Sixteen (16) Ports.
NetWay8: 115VAC 60Hz, 3A.
NetWay16: 115VAC 60Hz, 4.9A.
Fuse: 4A/125V (NetWay16 has 2 fuses).
Note: To reduce the risk of fire, replace only with same type and rating of fuse.
Port Status LED
Operating Ambient Temperature: UL60950-1: -20ºC to 40ºC (-4ºF to 104ºF).
Relative humidity: 85%, +/- 5%.
Storage Temperature: -20º to 70ºC (-4º to 158ºF).
Operating Altitude: -1000 to 10,000 ft. (-304.8 to 3048m).
UL/CUL Listed for Information Technology Equipment (UL 60950-1).
CE approved
Card
Reader
PoE Camera
HID Solo
PoE +
Camera
NVR/Network Server
Strike
NetWay1512
Netway1512
I.T.E.
Adapter
43KC
www.altronix.com
12VDC
IN OUT + Output ---
12VDC
IP camera
- 5 -
