Technical Specifications; Wall Mount Installation - Altronix NetWay1E Installation Manual

Fig. 1
OUT
Structured
Cable to
Network Switch
IP Camera
Parameter
No. of Ports
Input power requirements NetWay1E - 115VAC, 60Hz, 1.5 amp.
Indicators
PoE Shutdown Voltage
and Current Range
Environmental
Conditions
Regulatory Compliance

Wall Mount Installation

1- Install mounting brackets (A) on the left and right side of rack chassis using
four (4) flat head screws (B) (included) (Fig. 2a).
2- Place unit at desired location and secure with mounting screws
(not included) (Fig. 2b).
Caution: It is necessary to make sure mounting screws
are securely fastened to a beam when installing the
unit vertically.
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IINetWay1E/NetWay1EV Rev. 011612
- 2 -
PoE
IN Shutdown
PoE
ON
--- +
12VAC to 24VAC or
Structured 5VDC to 24VDC input
Cable from
for Remote Manual
PoE Shutdown

Technical Specifications:

Description
One (1)
NetWay1EV - 230VAC, 50/60Hz, 0.8 amp.
Port Status and power LED
5VDC to 24VDC or 12VAC to 24VAC. Maximum current: 2mA for 5VDC
Maximum current for higher voltages: 10mA.
Operating Ambient Temperature: 85W - 4ºF to 120ºF (-20ºC to 49ºC).
Relative humidity: 85%, +/ ---5%
Storage Temperature: ---4º to 158ºF (---20º to 70ºC) Storage
Operating Altitude: --- 1000 ft. to 2,000 ft. (--- 304.8m to 609.6m).
UL/CUL Listed for Information Technology Equipment (UL 60950-1).
CE approved.
55W - 4ºF to 131ºF (-20ºC to 55ºC).
Fig. 2a
B
D26M
Fig. 2b
A
MEMBER
NetWay1/NetWay1EV
