Parameter Description
NetWaySP2: Two (2) - Gigabit SFP Ports. Two (2) ports 10/100/1000 Mbps.
Number of Ports NetWaySP4: Four (4) - Gigabit SFP Ports. Four (4) ports 10/100/1000 Mbps.
NetWaySP8: Eight (8) - Gigabit SFP Ports. Eight (8) ports 10/100/1000 Mbps.
NetWaySP2: Two (2) outputs.
NetWaySP4: Four (4) outputs.
Power Outputs
NetWaySP8: Eight (8) outputs.
(All output power is dependent on input).
- 48-56V: UL Listed ITE power supply i.e. VertiLine563 (2 x 56V / 150W ports).
Input power requirements
- PoE+ (30W) or Hi-PoE (60W) (midspan/endspan)
Operating Ambient Temperature: 120W: -40ºC to 50ºC (-40ºF to 122ºF)
Relative Humidity: 85%, +/- 5%
Environmental Conditions
Storage Temperature: -40ºC to 85ºC (-40ºF to 185ºF).
Operating Altitude: -304.8 to 2,000m (-1,000 to 6,561.679 ft.).
Weights (approx.) NetWaySP4: Product: 2.55 lb. (1.16kg) | Shipping: 4.7 lb. (2.13kg).
Fig. 1
PoE+
Camera
PoE+
Camera
WiFi Access
Point
NetWaySP4
Front Panel
NetWaySP4
Rear Panel
Daisy Chaining
Power Inputs
www.altronix.com

Technical Specifications:

NetWaySP4 Typical Application:
NetWay
Spectrum
NetWay
PoE+
Spectrum
Hardened
PoE+ Switch
Hardened
Switch
PoE+
Camera
PoE+
Camera
WiFi Access
Point
Composite (Powered) Fiber Cable
Fiber Copper
Fiber Copper
Midspan/Endspan
Input Power Options
48-56V UL Listed
ITE Power Supply
- 3 -
PoE+
NetWay
Camera
Spectrum
PoE+
PoE+
Camera
Hardened
Switch
WiFi Access
Point
Fiber
Copper
NetWaySP2/4/8
