• Two-channel Input Capture can be used to time input signals from various port pins
• Two-channel Quadrature Decoder accepts inputs from external incremental encoder
devices
• Six CMOS-compatible serial ports: maximum asynchronous baud rate of 3.68 Mbps,
maximum synchronous baud rate of 7.35 Mbps. Four ports are configurable as a
clocked serial port (SPI), and two ports are configurable as SDLC/HDLC serial ports.
• Supports 1.15 Mbps IrDA transceiver
There are two production models in the RCM3100 series. If the standard models do not
serve your needs, other variations can be specified and ordered in production quantities.
Contact your Rabbit Semiconductor sales representative for details.
Table 1 below highlights the differences between the two models in the RCM3100 family.
Feature
Microprocessor
Flash Memory
Static RAM
Serial Ports
In addition, there is an RCM3000 series of RabbitCore modules that includes Ethernet con-
nectivity.
The RabbitCore modules can be programed locally, remotely, or via a network using
appropriate interface hardware.
Appendix A, "RabbitCore RCM3100 Specifications," provides detailed specifications for
the RCM3100.
2
Table 1. RCM3100 Versions
RCM3100
Rabbit 3000 running at 29.4 MHz
2 × 256K
512K
6 shared high-speed, CMOS-compatible ports:
6 are configurable as asynchronous serial ports;
4 are configurable as clocked serial ports (SPI);
2 are configurable as SDLC/HDLC serial ports;
1 asynchronous clocked serial port is dedicated
for programming
RCM3110
256K
128K
