Chapter 2 describes the hardware components and principal hardware
subsystems of the RCM3100. Appendix A, "RabbitCore RCM3100
Specifications," provides complete physical and electrical specifica-
tions.
Figure 4 shows these Rabbit-based subsystems designed into the RCM3100.
SRAM
Flash
User's Manual
4. H
ARDWARE
14.7 MHz
32 kHz
crystal
crystal
Battery-Backup
Circuit
Figure 4. RCM3100 Subsystems
R
EFERENCE
Customer-specific
applications
RS-232, RS-485, IrDA
serial communication
drivers on motherboard
