E.5 PWM Registers
There are no default values on reset for any of the PWM registers.
PWM LSBs Register
PWL0R
PWL1R
PWL2R
PWL3R
Bit(s) Value
7:6 Write
5:1
0 0
1
PWM MSB x Register
PWM0R
PWM1R
PWM2R
PWM3R
Bit(s) Value
7:0 write
User's Manual
Table E-4. PWM Registers
10001000 (0x88)
10001010 (0x8A)
10001100 (0x8C)
10001110 (0x8E)
The least significant two bits for the Pulse Width Modulator count are
stored
These bits are ignored.
PWM output High for single block.
Spread PWM output throughout the cycle
Address = 10001001 (0x89)
Address = 10001011 (0x8B)
Address = 10001101 (0x8D)
Address = 10001111 (0x8F)
The most significant eight bits for the Pulse-Width Modulator count
are stored
With a count of n, the PWM output will be high for n +1 clocks out of
the 1024 clocks of the PWM counter.
Address
Description
Address
Description
95
