Table 2. RCM3100 Pinout Configurations
Pin Pin Name
1 GND
2 STATUS
3–10 PA[7:0]
11 PF3
12 PF2
13 PF1
14 PF0
15 PC0
16 PC1
17 PC2
18 PC3
19 PC4
20 PC5
21 PC6
22 PC7
23 PG0
24 PG1
25 PG2
26 PG3
27 PD4
28 PD5
29* PD2
30* PD3
31* PD6
32* PD7
33* PD0
34* PD1
* Pins 29–34 are reserved for future RCM3100 RabbitCore modules.
20
Default Use
Output (Status) Output
External data bus
(ID0–ID7)
Parallel I/O
Slave port data bus
(SD0–SD7)
Input/Output QD2A
Input/Output QD2B
QD1A
Input/Output
CLKC
QD1B
Input/Output
CLKD
Output TXD
Input RXD
Output TXC
Input RXC
Output TXB
Input RXB
Output TXA
Input RXA
Input/Output TCLKF
Input/Output RCLKF
Output TXF
Input RXF
Input/Output ATXB
Input/Output ARXB
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Alternate Use
Serial Port D
Serial Port C
Serial Port B
Serial Port A
(programming port)
Serial Clock F output
Serial Clock F input
Serial Port F
RabbitCore RCM3100
Notes
