"Periscope" Lower Mirror (Mirror 4) Adjustment Diagram:
The diagram below illustrates the direction the Red Dot can be expected to move when the
indicated mirror adjustment screw is turned.
Top Allen
Lower right
Lower left
screw turned
Allen screw
Allen screw
clockwise
turned clockwise
turned clockwise
