Description
2.5

Wear compensation in direction of surface normal

Grinding a surface
This compensation type compensates for wear in surface normal direction. The surface normal direction is
calculated in the CNC based on the tool direction vector and the path tangent vector.
Z
Grinding wheel
ori1
fn1
Tool wear
ori2
fn2
ori3
tb1
fn3
tb2
Workpiece
tb3
X
Figure 12: Wear in surface normal direction
22
Version: 1.02
TF5200 | TwinCAT 3 CNC
Online tool compensation
