Description
General #OTC programming example
N10 F10000
N20 D1 (Data set selection for grinding wheel)
N30 G0 X0 Y0 Z0
N40 #OTC[RADIUS, AUTO] (OTC operation mode + define mode)
N50 #OTC ON (Select OTC)
N60 G41 G01 X50 (Select TRC, wear-free movement)
N70 X1000
N80 G40 X50 (Deselect TRC with path motion to reduce TRC)
N90 #OTC OFF (Deselect OCP)
N100 G00 X50
N199 M30
12
Version: 1.02
TF5200 | TwinCAT 3 CNC
Online tool compensation
