Parameter

3 Parameter
3.1

Overview

ID Parameter
P-TOOL-00001 typ
P-TOOL-00030 grinding_wear_const
P-TOOL-00031 grinding_max_infeed
P-TOOL-00032 grinding_tilt_angle
3.2

Description

P-TOOL-00001 Type
Description This parameter is assigned to distinguish between tool types.
Parameter wz[i].typ
Data type UNS16
Data range 0: Milling tool
1: Turning tool
2: Grinding tool
Dimension ----
Default value 0
Remarks Parameterisation example: Tool 5 is a milling tool
wz[5]typ 0
P-TOOL-00030 Wear constant
Description The wear constant is used to calculate continuous tool wear. Alternatively, it can
also be defined in the NC program (#OTC [...].
Parameter wz[i].grinding_wear_const
Data type REAL64
Data range 0 ≤ grinding_wear_const
Dimension 0.1µm/m
Default value 0
Remarks The wear constant should contain relatively small values. There is no special
dynamic consideration based on the actual wear values.
P-TOOL-00031 Maximum discrete infeed
Description The maximum discrete infeed defines the greatest relative change which is
assignable by the PLC.
Parameter wz[i].grinding_max_infeed
Data type REAL64
Data range MIN(SGN32) ≤ grinding_max_infeed ≤ MAX(SGN32)
Dimension 0.1µm
Default value 0
Remarks
P-TOOL-00032 Grinding disc tilt angle
Description The parameter defines the angle between the centre line of the grinding disc and the
3rd main axis for tilted grinding discs.
Parameter wz[i].grinding_disc_tilt_angle
32
Description
Tool type
Wear constant
Maximum discrete input
Grinding disc tilt angle
