Description
2.3.1

Inclined grinding disc

Inclined grinding
The incline of the grinding disc is only entered in the tool list (P-TOOL-00138) to grind inclined surfaces.
Here the complete lateral surface of the grinding disc is also in contact.
The figure below shows the orientation of the tilt angle using the example of the G17 plane:
Figure 7: Inclined grinding disc
18
X/Y plane with G17
a
negative
a
a positive
a is 0
Version: 1.02
Z
Turning point of disc
a
X
