Jumpers

JP1
A1
JP9
A2
J3
A3
JBAT1
A4
Back-Panel Connectors
KB
B1
MS
B1
LAN
B2
USB
B3
COM1
B4
VGA
B5
PRINTER
B6
LINE-OUT
B7
LINE-IN
B8
MIC-IN
B9
GAME/MIDI
B10
Front-Panel Connectors (JP5 and JP8)
PTSW
C1
HDLED
C2
GLED/PLED
C3
PLED
C4
RST
C5
SPK
C6
JP8
C7
Internal Peripherals Connectors
FDD
D1
IDE1
D1
IDE2
D1
: USB1/2 Power-On Setting
: USB3/4 Power-On Setting
: FSB Speed Configuration Setting
: Clear CMOS
: PS/2 Keyboard
: PS/2 Mouse
: RJ45 LAN Port
: 2 × USB (Universal Serial Bus)
: Serial Port 1 (DB9 male)
: VGA Port (DB15 female)
: Parallel Port (DB25 female)
: Line-Out Port
: Line-In Port
: Mic-In Port
: MIDI/Game Port
: ATX Power On/Off Momentary Type Switch
: IDE Drive Active LED
: Green LED (ON when system stays in power saving mode)/
System Power LED
: System Power LED
: Hardware Reset Switch
: Housing Internal Speaker
: Extended USB Header (USB Port 3/4)
: Floppy Disk Drive Interface
: IDE Primary Interface (Dual-channel)
: IDE Secondary Interface (Dual-channel)
- 26 -
