NetXtreme-E User's Manual

Configuring Paravirtualized RDMA Network Adapters

Please refer to the vmware link below for additional information on setting up and using Paravirtualized RDMA
(PVRDMA) network adapters.
https://pubs.vmware.com/vsphere-65/index.jsp#com.vmware.vsphere.networking.doc/GUID-4A5EBD44-
FB1E-4A83-BB47-BBC65181E1C2.html

Configuring a Virtual Center for PVRDMA

To configure a Virtual Center for PVRDMA:
1. Create DVS (requires a Distributed Virtual Switch for PVRDMA)
2. Add the host to the DVS.

Tagging vmknic for PVRDMA on ESX Hosts

To tag a vmknic for PVRDMA to use on ESX hosts:
1. Select the host and right-click on Settings to switch to the settings page of the Manage tabs.
2. In the Settings page, expand System and click Advanced System Settings to show the Advanced System
Settings key-pair value and its summary.
3. Click Edit to bring up the Edit Advanced System Settings.
Filter on PVRDMA to narrow all the settings to just
4. Set the
Net.PVRDMAVmknic

Setting the Firewall Rule for PVRDMA

To set the firewall rule for PVRDMA:
1. Select the host and right-click on Settings to switch to the settings page of the Manage tabs.
2. In the Settings page, expand System and click Security Profile to show the firewall summary.
3. Click Edit to bring up the Edit Security Profile.
4. Scroll down to find pvrdma and check the box to set the firewall.

Adding a PVRDMA Device to the VM

To add a PVRDMA device to the VM:
1. Select the VM and right-click on Edit Settings.
2. Add a new Network Adapter.
3. Select the network as a Distributed Virtual Switch and Port Group.
4. For the Adapter Type, select PVRDMA and click OK.
February 26, 2018 • NetXtreme-E-UG100
value to vmknic, as in example vmk0
RoCE – Configuration and Use Case Examples
.
Net.PVRDMAVmknic
Page 71
