Network Link and Activity Indication

BCM957402AXXXX/BCM957412AXXXX

The SFP+ port has two LEDs to indicate traffic activities and link speed. The LEDs are visible through the cutout
on the bracket as shown in
Figure 7: BCM957402AXXXX/BCM957412AXXXX Activity and Link LED Locations
Port 1 SFP+ Cage
Port 1 Activity LED
Port 2 SFP+ Cage
Port 2 Activity LED
Table 6: BCM957402AXXXX/BCM957412AXXXX Activity and Link LED Locations
LED Type
Activity
Link
February 26, 2018 • NetXtreme-E-UG100
Figure 7. The LED functionality is described in
Color/Behavior
Off
Green blinking
Off
Green
Network Link and Activity Indication
Table 6.
Port 1 Link LED
Port 2 Link LED
Note
No Activity
Traffic Flowing Activity
No Link
Linked at 10 Gbps
