NetXtreme-E User's Manual

DCBX Mode = Enable (IEEE only)

This option allows a user to enable/disable DCBX with the indicated specification. IEEE only indicates that
IEEE802.1Qaz DCBX is selected.
Windows Driver setting:
After enabling the indicated options in the UEFI HII menu to set firmware level settings, perform the follow
selection in the Windows driver advanced properties.
Open Windows Device Manager -> Broadcom NetXtreme E Series adapter -> Advanced Properties ->
Advanced tab
Quality of Service = Enabled
Priority & VLAN = Priority& VLAN enabled
VLAN = <ID>
Set desired VLAN id
To exercise the DCB related command in Windows PowerShell, install the appropriate DCB Windows feature.
1. In the Task Bar, right-click the Windows PowerShell icon and then click Run as Administrator. Windows
PowerShell opens in elevated mode.
2. In the Windows PowerShell console, type:
Install-WindowsFeature "data-center-bridging"

DCBX Willing Bit

The DCBX willing bit is specified in the DCB specification. If the Willing bit on a device is true, the device is willing
to accept configurations from a remote device through DCBX. If the Willing bit on a device is false, the device
rejects any configuration from a remote device and enforces only the local configurations.
Use the following to set the willing bit to True or False. 1 for enabled, 0 for disabled.
Example
set-netQoSdcbxSetting -Willing 1
Use the following to create a Traffic Class.
C:\> New-NetQosTrafficClass -name "SMB class" -priority 4 -bandwidthPercentage 30 -Algorithm ETS
Note: By default, all 802.1p values are mapped to a default traffic class, which has 100% of the
bandwidth of the physical link. The command shown above creates a new traffic class to which any
packet tagged with eight IEEE 802.1p value 4 is mapped, and its Transmission Selection Algorithm
(TSA) is ETS and has 30% of the bandwidth.
It is possible to create up to seven new traffic classes. In addition to the default traffic class, there is
at most eight traffic classes in the system.
Use the following in displaying the created Traffic Class:
February 26, 2018 • NetXtreme-E-UG100
DCBX – Data Center Bridging
Page 74
