NetXtreme-E User's Manual
BCM957406AXXXX/BCM957416AXXXX
The RJ-45 port has two LEDs to indicate traffic activities and link speed. The LEDs are visible through the cutout
on the bracket as shown in
Figure 9: BCM957406AXXXX/BCM957416AXXXX Activity and Link LED Locations
Table 8: BCM957406AXXXX/BCM957416AXXXX Activity and Link LED Locations
LED Type
Activity
Link
February 26, 2018 • NetXtreme-E-UG100
Figure
9. The LED functionality is described in
Color/Behavior
Off
Green blinking
Off
Green
Amber
Network Link and Activity Indication
Table
8.
Notes
No Activity
Traffic Flowing Activity
No Link
Linked at 10 Gbps
Linked at 1 Gbps
Page 16
