CH<x>:PRObe:FORCEDRange
The command selects the dynamic range of probe (1 of 9) in +/-V. It is dependent on the attached probe tip. The channel is
specified by x. The command should only be used when CH<x>:PROBECONTROL is set to MANUAL.

Table 12: Probe tip cables and dynamic ranges

Probe tip cable
No tip or 1X tip
10X
50X
100X
500X
The query returns the dynamic range of the probe tip in +/-V.
Syntax
Arguments
Examples
CH<x>:PRObe:GAIN? (Query Only)
The command returns the gain factor of the currently selected range (inverse of attenuation). The channel is specified by x.
Syntax
Examples
CH<x>:PRObe:ID? (Query Only)
This query-only command returns the type and serial number of the probe that is attached to the specified channel. The
channel is specified by x.
Syntax
Examples
TIVP Series IsoVuTM Measurement System User Manual
Dynamic Range +/-V
0.02 | 0.04 | 0.08 | 0.16 | 0.32 | 0.64 | 1.28 | 2.56 | 5.0
0.2 | 0.4 | 0.8 | 1.6 | 3.2 | 6.4 | 12.8 | 25.6 | 50.0
1.0 | 2.0 | 4.0 | 8.0 | 16.0 | 32.0 | 64.0 | 128.0 | 250.0
2.0 | 4.0 | 8.0 | 16.0 | 32.0 | 64.0 | 128.0 | 256.0 | 500.0
10.0 | 20.0 | 40.0 | 80.0 | 160.0 | 320.0 | 640.0 | 1280.0 |
2500.0
CH2:PRObe:FORCEDRange <NR3>
CH2:PRObe:FORCEDRange?
<NR3> specifies the probe dynamic range
If a current probe is attached to the Channel 1 input,
CH1:PROBE:FORCEDRANGE 5.0 sets the attached probe to its 5 V range.
CH3:PROBE:FORCEDRANGE? might return 5.0000, indicating that the range
of the probe attached to the Channel 3 is set to 5 V.
CH<x>:PRObe:GAIN?
CH2:PROBE:GAIN? might return 100.0000E-3, indicating that the attached
10X probe delivers 0.1 V to the Channel 2 BNC for every 1.0 V applied to the probe
input.
CH<x>:PRObe:ID?
CH2:PROBE:ID? might return "B010289";"TIVP1", indicating that a
TIVP1 probe with serial number B010289 is attached to Channel 2.
Remote programming
